Float Valve Identification Poster - Digital Download

The Safety Shark Float Valve Identification Poster provides a detailed, visual reference for identifying, assembling, and understanding API float valves used in drilling operations. Designed for use on rig sites, workshops, and training facilities, this poster simplifies valve selection and maintenance by clearly showing Model F (Plunger Type) and Model G (Flapper Type) configurations with labelled components and API thread details.

✅ Key Features:

• Full visual breakdown of Model F (Plunger Type) and Model G (Flapper Type) float valves

• Clear labelling of internal components, including valve seal disc, plunger, spring, cage, and side seals

• Displays API thread configurations including API Regular, API Full Hole, and API Internal Flush types

• Colour-coded reference for component orientation and part recognition

• Ideal for driller’s cabins, toolpushers, maintenance workshops, and training classrooms

• Printed in high resolution with Safety Shark branding for durability and clarity

• Available in digital or physical poster formats

📘 Included Reference Data:

• Valve assembly diagrams (1F2R / 2F3R / 5F6R etc.)

• Thread type chart and valve compatibility guide

• Component numbering key for maintenance and ordering reference

💡 Applications:

• Drilling operations

• Equipment maintenance and training

• Quick reference in rig tool rooms or inspection areas

🦈 Safety Shark Tip:
Always confirm your float valve model before replacement or maintenance. Using the correct valve type reduces the risk of mud loss, backflow, and pressure imbalance during drilling.
